Custom Components and Reverse Engineering for Mold and Die
Not every component you need is in a catalog. When your mold or die requires a custom solution, or when a legacy part is no longer available, Tooling Components delivers.
Custom Component Design and Manufacturing
We work with your team to design and build custom components to your exact specifications. Whether you need a non-standard pin diameter, a specialized bushing, or a one-off die component, our engineers can create it.
- Custom leader pins and bushings in any diameter and length
- Specialized ejector pins for complex part geometries
- Custom core pins for unique mold cavity requirements
- Modified die set components to match existing tooling
- Non-standard materials and surface treatments
Reverse Engineering of Obsolete Parts
Replacing an entire mold or die because one component is obsolete can cost tens of thousands of dollars in downtime and retooling. Our reverse engineering service extends the life of your existing equipment.
Our process:
- Evaluation: We review the part and determine the best approach
- Measurement: Precision measurement of all critical dimensions
- Material Analysis: Identification of the original material grade and hardness
- Fabrication: Manufacturing the replacement part to original specifications
- Quality Check: Dimensional and material verification before delivery
When to Use Reverse Engineering
- Original manufacturer no longer supplies the part
- Lead time from OEM is unacceptable
- Part has been discontinued
- You have a legacy mold or die that is otherwise functional
- You want to improve on an original design with modern materials
Industries We Support
Automotive, medical device, aerospace, consumer goods, and general industrial manufacturers rely on Tooling Components for custom and reverse-engineered parts. Located in Union City, PA, we serve the entire Great Lakes and Northeastern manufacturing corridor.
Have a custom component need or an obsolete part to replace? Submit your drawings or the original part to our team for a same-day quote.
